Fiberwood Composite Panel

Fiberwood Panels

Fiberwood is a maintenance-free. The product is with A1 fire class, which is easy to apply with a cost of 1/5.

Advantages of Use: Stocking Advantage, Accessibility, Ease of Transport, Ease of Installation, Dyeability, Ease of Application





Standard Dimensions



Thickness  10, 12 mm
Weight 55, 65 kg
Dimensions 1250 x 3000 mm

Technical Specifications



Density  1150 ± 75 kg/m³
Fire resistance  EN 13501-1 Class A1 building material
Bending strength   ≥ 7 N/mm2
Elastic module in bending   ≥ 4000 N/mm2

TCW2002



TCW2010



TCW2008



TCW2004



TCW2014



TCW2012



TCW2006



Application of Features

  • Resistant to seasonal changes.
  • Easy assembly and modification procedures.
  • It is odorless and does not release toxic gas.
  • Extends and protects the life of insulation material when used in heat and sound insulation systems.
  • It provides durability to impact
  • Resistant to biological and chemical wastes.
  • Easy to carry, light weight.
  • Insect-proof, non-putrescible, fungusproof.
  • Easy to cut.
  • Offers different solutions in all areas of building projects.
  • A finishing material.
  • Can be painted again.
  • Cement based.
  • Can be used with insulating material of any desired thickness.
  • Can be used in fine details with smooth cutting surfaces.
  • Highly impact resistance rather than gypsum based board.
  • Protects the under construction system.
  • Create facades and surfaces in according to fire instructions and regulations.
  • Applied as Natura Deck

Packaging / Storage / Handling





  • Our panels are transported domestically and internationally with the plate edges painted.
  • The panels are on wood pallets covered in plastic with rings and corner brackets added.
  • During transport the panels must be covered in canvas.
  • When the panels are being carried one by one they are recommended to be carried vertically or as close as possible to vertical so as not to be bent.
  • The panels must be stored in a closed area.
  • Whether in storage or at the assembly site the panels must be left in lateral position and should not be leaned either laterally or vertically on a wall or similar surfaces.
  • If the panel packages are to be stacked caution should be taken to align them.
  • If the panels are not going to be used for a long period the packages should be completely covered in plastic to avoid being affected from heat and humidity change (stay stable).
  • After panels are taken from the package to be used the package should be covered over again with the plastic.
  • The storage area must be closed.
  • When stacking pallets the pallet feet should be lined up one on top of the other.
  • Do not take the plastic cover off until use.
  • Do not take off the steel strips until use.
  • The materials should be placed on the smoothest ground possible.
  • When storing, pallets should be placed on top of each other neatly and the total height of pallets should not be over 3 meters.
  • When loading, only two pallets at a time should be loaded.
  • When loading make sure that the pallets are placed on the truck in a balanced way.
  • Pallets ready for transport
